Guide 7-in Wall Sconce

SKU:WS33407-BG

Implementing an edge-lit LED optical assembly results in a singular plane of diffusive glowing luminance. The GUIDE interior wall lamp obscures the radiant source within a precision-machined aluminum body. Slightly offset from the wall the orthogonal reductive fixture provides an optimal architectural accent. Custom patterns or text may replace the uniform translucence of the light guide.

Where to Buy

Technical Description

Solid machined-aluminum support with rectangular wall mount
Edge-lit translucent acrylic panel
Finely brushed finish
Custom options available

Specifications

Family	Guide
Color Temperature	3000K
Fixture Dimensions	6 W x 7 H x 1-1/2 E
Primary Dimension	7-in
Location Rating	Dry
Wattage	7W
Dimming Range	100% - 10%
Dimming Type	ELV Dimmer (Not Included)
CRI	90CRI
LED Total Lumens	495lm
Fixture Delivered Lumens	BG-305lm, BK-275lm
LED Life Span	50,000 hours
Fixture Input Voltage	120V
Illumination Direction	Up and Down
Mounting Style	All Orientation\|Wall
Glass Details	Frosted Glass
ETL Compliant	Yes
ADA Compliant	Yes
Country Of Origin	CHINA
